| Specifications |
Unit |
RTV-855C |
| Workbench Size (L x W) |
mm |
1100 X 550 |
| X/Y/Z Axis Travel |
mm |
800/550/550 |
| Control System |
– |
Syntec 22MA |
| Spindal Motor Power (Conti/30 min) |
Kw |
11/15 |
| X/Y/Z Axis Motor Power |
Nm |
15/15/28 |
| Spindal Max. Speed |
rpm |
8000 (Ring Coolant) |
| ATC Type |
– |
Arm Type |
| No of Tools |
Pcs |
24 |
| Tools Weight Capacity |
kg |
9 |
| X/Y/Z Roller Guide Rail Width Size |
mm |
35/45/45 |
| X/Y/Z Ball Screw C3 Class (Dia. X Pitch) |
mm |
40 X 16 |
| Distance From Table Top to Spindal End |
mm |
120-670 |
| Distance From Spindal Center to Column |
mm |
590 |
| Max. Weight Carrying Capacity |
kg |
600 |
| X/Y/Z Axis Rapid Feed |
m/min |
24/24/20 |
| No of Blocks X/Y/Z |
Pcs |
4 X 4 X 6 |
| Workbench T-Slot |
N-H-W |
5-18-90 |
| Tool Change Time |
Sec. |
1.8 / 4 |
| Possition Accuracy |
mm |
± 0.005 |
| Repetability |
mm |
± 0.003/300 |
| Minimum Positioning Unit |
mm |
0.003 |
| Machine Weight |
kg |
5200 |
| Dimensions ( L X W X H ) |
mm |
2600 X 2300 X 2650 |
