| Specifications |
Unit |
RT 200-5Y |
| Swing Over Bed |
mm |
660 |
| Maximum Cutting Dia. |
mm |
250 |
| Maximum Cutting Length |
mm |
500 |
| Chuck Size |
mm |
200 |
| Control System |
– |
SYNTEC 22TB |
| X Axis Travel |
mm |
420 |
| Z Axis Travel |
mm |
520 |
| Y Axis Travel (Center To Up & Down) |
mm |
50/50 |
| Spindle Nose |
– |
A2-6 |
| Bar Capacity |
mm |
52 |
| Spindle Speed |
rpm |
4500 |
| Live Tool Speed |
rpm |
5000 |
| Spindle Motor Power |
Kw |
11 |
| Axis Motor X/Y/Z |
Nm |
11.5 |
| Rapid Feed X/Y/Z |
m/min |
24/24/24 |
| Linear Roller Guideways X/Z |
mm |
35/35 |
| Ball Screw Size X/Z |
mm |
32×10/32×10 |
| Turret Tool |
Nos |
15 |
| Tool Size |
mm |
25/25 |
| Power Head Size |
Nm |
ER25 |
| Position Accuracy X/Z |
mm |
± 0.003 |
| Turret Specification |
– |
Servo Hydraulic (Taiwan) |
| Repeatability |
mm |
± 0.005 |
| Total Machine Power |
hp |
26 |
| Over All Dimension ( L X WXH) |
mm |
2500X1700X2000 |
| Machine Weight (Approx) |
Kg |
3600 |
