Technical Specifications:
| Specifications | Unit | CK 640 |
|---|---|---|
| Swing Over Bed | mm | 410 |
| Maximum Cutting Dia. | mm | 160 |
| Maximum Cutting Length | mm | 205 |
| Chuck Size | mm | 165 |
| X Axis Travel | mm | 500 |
| Z Axis Travel | mm | 210 |
| Bar Capacity | mm | 40 |
| Spindle Nose | – | A2-5 |
| Spindle Speed | rpm | 2800 |
| Spindle Motor Power | kw | 3.7 |
| Rapid Feed X/Z | m/min | 20/20 |
| Ball Screw Size X | mm | 25/8 |
| Ball Screw Size Z | mm | 32/10 |
| Linear Guideways X/Z | mm | 30/35 |
| Axis Torque X/Z | N.m | 6/6 |
| Tool Cross Section | mm | 20/20 |
| Max Boring Block | mm | 32 |
| Position Accuracy | mm | ± 0.003 |
| Repeatability | mm | 0.003 |
| Total Machine Power | hp | 12 |
| Overall Dimension (LxWxH) | mm | 2300 X 1750 X 1905 |
| Machine Weight (Approx) | kg | 1800 |
